Description
Indications
- Non-surgical treatment of PCL ruptures.
- Post-surgical rehabilitation for partial PCL tears or PCL reconstruction/revision.
Functions
- Knee joint ROM control.
- Prevent hyperextension via adjustable hinge ROM.
Features
- Provide shin anterior force with dynamic PCL Pad and integrated tensioning dial.
- Tool-less ROM Hinge with stops cover makes sure angle stop in right place.
- ROM hinges with plug-in flexion/extension stops.
Extension limitation at: 0°,10°,20°,30°,40°,45°
Flexion limitation at: 0°,10°,20°,30°,45°,60°,75°,90°,100°,120° - Ultra-light weight aluminum alloy frames decrease the loading on knee joint.
- Heat molded EVA foam paddings without stitching seam and have anti-slip silicon.
- Anatomically shaped femoral condyle pads ensure optimal knee joint contact.
- 4 points of leverage design provides superior stability.
- Labeled number straps guide the application sequence clearly.
Size: S | M | L | XL(Left/Right)
Measure circumference of thigh and calf
| SIZE | S | M | L | XL |
|---|---|---|---|---|
| Thigh circumference(cm) | 31-39 | 39-47 | 47-54 | 54-60 |
| Calf circumference(cm) | 21-29 | 29-37 | 37-43 | 43-50 |
